T-700 LTD
Shimano Deore XT 30-speed / HS22
From comfortable to sporty – in order to meet the trekking bike requirements of different types of riders, we offer the popular T-700 in various configurations. For riders who like to be more sporty on their trekking bike, this version, with a Shimano Deore XT 30-speed shifter, is the right choice.
As befits an „everyday trekking bike“, the total configuration of this trekking bike in combination with the handcrafted steel frame provides a maximum of comfort, cycling pleasure, and durability: Ritchey headset, Selle royal saddle, Shimano XT disc brakes, Racktime pannier rack, Ergon grips, SKS fenders, and much more.
The T-700 Shimano XT 30-speed. Sporty cycling pleasure guaranteed.
In addition to the standard colors, this model is available in other special colors for an additional fee. For more detailed information on the costs of color customisation, please contact your dealer.
You can find all the information about our color world here.
- Framesize
- Diamant 28": 52, 57, 62 cm
Trapez 28": 45, 50, 55 cm - Frame
- 25 CrMo 4, double butted
- max load
- 140 kg
- Colour
- slate glossy, midnight glossy
- Head set
- Ritchey Comp Logic V2
- Fork
- 28" aluminum,
- Shifting System
- Shimano Deore XT RD-T8000, 10-speed
- Derailleur
- Shimano Deore XT FD-T8000, 3-speed
- Brakes
- Magura HS22, incl. Brakebooster Rim brake
- Headlights
- Busch & Müller Lumotec IQ-XS, 70 LUX including standinglight
- Rear light
- Busch & Müller Toplight 2C plus, including standinglight
- Carriers
- Racktime Light-it
- Saddle
- Selle Royal Essenza
- Seat post
- Humpert Ergotec Atar, aluminum, 27,2 mm, 300 mm
- Pedals
- Marwi SP-823
- Kickstand
- Atran Velo Atran Velo Parko, rear kickstand
- Chainguard
- Shimano chainguard
- Mudguard
- SKS, plastic
- Weight
- 13,9 kg
- Stem
- Levelnine, aluminum, a-head, 25,4 mm
- Handlebars
- Levelnine, Trekking, aluminum, 640 mm
- Grips
- Ergon GP1, with clamp
- Shift lever
- Shimano Deore XT SL-T8000, 3-/10-speed, with gear display
- Brake lever
- Magura HS22, 3-fingerlever
- Tires
- Schwalbe Marathon Racer, 40-622, reflex
- Spokes
- Niro 2,0 mm
- Front Hub
- Shutter Precision PV-8, hub dynamo, 36 holes
- Rear Hub
- Shimano Deore FH-T610, 36 holes
- Sprocket
- Shimano Deore XT CS-M771, 10-speed, 11-36 teeth
- Chain
- KMC X10
- Inner bearing
- Shimano BB-MT501, für Hollowtech II, BSA
- Crank wheel set
- Shimano Deore XT FC-T8000, 170 mm, Hollotech II, 48/36/26 teeth
- Gear ratio (front:rear)
- 48/36/26 teeth : 11-36 teeth
Technical changes and changes in equipment reserved, color deviations possible.
- Trapez 28" 45 cm / 50 cm / 55 cm
- Diamant 28" 52 cm / 57 cm / 62 cm
slate glossy (only Diamant)
midnight glossy (only Trapez)
